Product Description:

Prosport Coilovers for Mercedes-Benz SLK R170

Key Features:

Zinc-plated coilover struts for a quality finish with enhanced corrosion protection.

Blue Powder-Coat finish on the springs.

Progressively wound front and rear springs.

All-metal ride height adjusters

Engineered to give the best balance between firmly controlled handling and comfort.

Fits:

This Prosport Coilover Kit will fit these Mercedes-Benz SLK R170 models made from 1996-2004:

200 / 200 Kompressor / 230 Kompressor / 320

Not suitable for 4Matic (4x4) versions Self-Levelling or AMG Models.

The O.E.rubber top mount dish is available in several heights. Exchanging this dish can influence the lowering effect by up to 15 mm

Lowering Range:

Front: 65-80mm

Rear: 35-45mm

Product Specifications in Detail:

Front Shock Absorber Type: Twin-Tube with pressurised gas

Rear Shock Absorber Type: Twin-Tube with pressurised gas

Front Spring Type: Progressively wound

Rear Spring Type: Progressively wound

Maximum Front Axle Load: 905kg

Maximum Rear Axle Load: 850kg

Silver painted and lacquered front and rear shock absorbers

Blue EPS Powder Coating on the springs

All metal rear height adjusters with anodised finish

Good to Know:

These Prosport Coilovers are designed to fit on to the standard (OEM) top mounts.

No additional parts needed for installation of this Prosport Coilover Kit.

TUV Quality Certification.

1 year warranty.

We recommend having the suspension geometry checked and adjusted after fitting these Coilovers.

To ensure both optimum performance and reliability always keep within the lowering range shown above.

Vehicles with factory-fitted sport suspension will lower by less than the stated figures

In the box:

Front Uprated Shortened Shock Absorbers

Front Lowering Springs with Ride-height Adjusters

Rear Uprated Shortened Shock Absorbers

Rear Lowering Springs with Ride-height Adjusters

Tools for setting ride height

Kit Number: 150262
